| Product |
Legion 5
15IRX10 |
| Model |
83LY00REMH |
| PERFORMANCE |
| Processor |
Intel
Core™ i7-13650HX, 14C (6P + 8E) / 20T, P-core up to 4.9GHz, E-core up to
3.6GHz, 24MB Intel® Smart Cache |
| AI PC Category |
AI-Powered
Gaming PC |
| NPU |
None |
| Graphics |
NVIDIA
GeForce RTX™ 5060 8GB GDDR7, Boost Clock 2497MHz, TGP 115W, 572 AI TOPS |
| Chipset |
Intel®
HM770 Chipset |
| Memory |
1x
16GB SODIMM DDR5-4800 |
| Memory Slots |
Two
DDR5 SODIMM slots, dual-channel capable |
| Max Memory |
Up
to 32GB DDR5-4800 offering |
| Storage |
512GB
SSD M.2 2242 PCIe® 4.0x4 NVMe® |
| Storage Slot |
Two
M.2 2280 PCIe® 4.0 x4 slots |
| Max Storage
Support |
Up
to two drives, 2x M.2 SSD
• M.2 2242 SSD up to 1TB each |
| Optical |
None |
| Card Reader |
No
card reader |
| Audio Chip |
High
Definition (HD) Audio, Realtek® ALC3287 codec |
| Speakers |
Stereo
speakers, 2W x2, audio by HARMAN, optimized with Nahimic Audio |
| Microphone |
2x,
Array |
| Camera |
HD
720p with E-shutter |
| Battery |
80Wh |
| Power Adapter |
245W
Slim Tip (3-pin) |
| Special
Features |
AI
Chip: LA1 |
| DESIGN |
| Display |
15.3"
WUXGA (1920x1200) IPS 300nits Anti-glare, 100% sRGB, 165Hz, Dolby Vision® |
| Touchscreen |
None |
| Screen-to-Body
Ratio |
IPS
models: 90.9% AAR (active area ratio) |
| Color
Calibration |
Factory
Color Calibration |
| Pen |
Pen
Not Supported |
| Keyboard |
White
Backlit, English (EU) |
| Touchpad |
Buttonless
Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x
120 mm (2.95 x 4.72 inches) |
| Dimensions
(WxDxH) |
344.9
x 255.35 x 22.50-23.99 mm (13.58 x 10.05 x 0.89-0.94 inches) |
| Weight |
Starting
at 2.1 kg (4.63 lbs) |
| Case Color |
Eclipse
Black (with White Backlit Keyboard) |
| Case Material |
PC-ABS
+ 15% Talc (Top), PC-ABS + 15% Talc (Bottom) |
| Surface
Treatment |
Painting |
| SOFTWARE |
| Operating
System |
Windows®
11 Home, Benelux (EN/FR/DE/NL) |
| Bundled
Software |
Office
Trial + Lenovo® AI Now |
| CONNECTIVITY |
| WLAN +
Bluetooth |
Wi-Fi®
6, 802.11ax 2x2 + BT5.2 |
| WWAN |
WWAN
Not Supported |
| Ethernet |
100/1000M
(RJ-45) |
| Standard
Ports |
2x
USB-A (USB 5Gbps / USB 3.2 Gen 1), 1x USB-A (USB 5Gbps / USB 3.2 Gen 1),
Always On, 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with USB PD 95-100W and
DisplayPort™ 2.1, 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with DisplayPort™
1.4, 1x HDMI® 2.1, up to 8K/60Hz, 1x Headphone / microphone combo jack
(3.5mm), 1x Ethernet (RJ-45), 1x Slim tip (rectangle) power connector |
| Docking |
Various docking solutions supported via
USB-C®.
For more compatible docking solutions, please visit Docking for Legion 5
15IRX10 |
| SECURITY & PRIVACY |
| Security Chip |
Firmware
TPM 2.0 Enabled |
| Fingerprint
Reader |
No
fingerprint reader |
| Other Security |
E-shutter |
| SERVICE |
| Base Warranty |
2-year,
Courier or Carry-in with 1-year Battery |
| Included
Upgrade |
None |
| ACCESSORIES |
| Bundled
Accessories |
None |
| CERTIFICATIONS |
| Green
Certifications |
ENERGY
STAR® 9.0, EPEAT Gold Registered, ErP Lot 6/26, RoHS compliant |
| Other
Certifications |
TÜV
Rheinland® Low Blue Light (Hardware Solution) |
| Model Information |
| Machine Type |
83LY |
| Region |
WE |
| Country/Region |
Netherlands |
| TopSeller |
No |
| EAN / UPC /
JAN |
199273996506 |
| Announce Date |
2025-11-24 |
| End of Support |
2031-05-24 |
